Software for 2D and 3D simulation of electromagnetic fields

ANSYS Maxwell

Software for 2D and 3D simulation of electromagnetic fields








Software exposé

ANSYS Maxwell for electromagnetic field simulations

ANSYS Maxwell is a powerful and user-friendly simulation software for the two-dimensional and three-dimensional calculation and visualisation of low-frequency electric and magnetic fields. The models can be viewed in a simplified stationary or harmonic manner. However, a realistic transient view including the consideration of movements is also possible. The finite element method with automatic adaptive meshing is available for the calculation.

The software offers an intuitive user interface and supports data import from common ECAD and MCAD systems. A major advantage of the Maxwell software is the automated solution process. The user only has to worry about geometry, material properties, boundary conditions, excitations and output parameters. Other aspects are taken care of by the Maxwell software, in particular the mesh generation. The numerical parameters required for the simulation are specified automatically.

Extract from the features

  • Simulation of electric and magnetic fields (static, harmonic, dynamic)
  • Simulation as a 3D or 2D model (with translational or rotational symmetry)
  • Calculation of resistances, impedances, capacitances and inductances
  • Visualisation of forces, torques, magnetisation and demagnetisation
  • Calculation of eddy currents and current displacement (skin effect)
  • Dynamic calculation with all transient magnetic effects
  • Fast and efficient design of electromagnetic components and machines as well as design verification and design optimisation using simulation
  • Implementation of parameter variations, optimisations, sensitivity and statistical analyses

ANSYS Maxwell relies on an adaptive meshing method in which a coarse starting mesh is automatically generated and repeatedly refined locally in the areas of greatest solution error until a specified accuracy is achieved in the solution. This maximises user-friendliness for the development engineer.

A free test installation to evaluate the software is available on request!

Target groups:

Engineers and designers from electrical engineering, electronics, mechatronics

Contact information:

Functions (excerpt) of ANSYS Maxwell:

2D representation
3D representation
Analysis functions
Collaboration
Data exchange
DX/DWG
DXF and DWG import
Graphical editing
Construction aids
Multilayer
Raster processing
Simulation
Workflow status

Price

on request

Get to know the software better! Request a video appointment for a personal presentation!

Technical specifications:

Web-based:
no
SaaS, Cloud:
no
On-premises (local installation):
yes
Multi-user (network-compatible):
yes
Maintenance:
included in price
First installation (year):
1990
number of installations:
>500
Vendor based in:
Germany
Training:
for a fee
Hotline:
included in price
Installation support:
included in price
Dialogue language(s):
English
System requirements:
Compatible operating systems (runs with):
Win 11
Win 10
Win 8
Win 7
Win Server
Mainframe based
Unix based
Linux based
Mac OS
Mobile OSs (supports):
iOS
Android
Old Compatible Operating Systems:
Win Vista
data storage medium:
DVD
CD-ROM
Download

More software of the vendor:

ANSYS CFD (CFX and FLUENT)
ANSYS Simplorer / Ansys TwinBuilder - System Simulation
Flownex® SE
